通过 CSS 插入 SVG

2021 年 9 月 24 日更新

经过尝试还是用文本块 + 软换行效果最好.

使用 Flex 布局,文本块缺少额外的标签包裹.

Grid 布局需要设置行数与列数,没有办法达到最好的显示效果.

正文

通过 CSS 插入 SVG 图标,具体方法

• iconfont-阿里巴巴矢量图标库 下载需要的图标. 演示的图片下载的是大小为 32 的图标

• 在线编码转换 (oschina.net) 把下载的 SVG 用记事本打开,复制源码.


效果

模板

Error:
{: style="background-color: var(--b3-card-error-background);" custom-blockinfo="error"}

Info:
{: style="background-color: var(--b3-card-info-background);" custom-blockinfo="info"}

Success:
{: style="background-color: var(--b3-card-success-background);" custom-blockinfo="success"}

Warning:
{: style="background-color: var(--b3-card-warning-background);" custom-blockinfo="warning"}

CSS

/*Block_Warning*/
[data-node-id][custom-blockinfo=warning]{
	flex-direction:row;
	display: flex;
	justify-content:flex-start;
	align-items: center;
}
[data-node-id][custom-blockinfo=warning]::before{
	margin-right:10px;

}
[data-node-id][custom-blockinfo=warning] [contenteditable]{
	border-left:2px solid #e6af99AA;
	padding-left:10px;
}
/*Block_Error*/
[data-node-id][custom-blockinfo=error]{
	flex-direction:row;
	display: flex;
	justify-content:flex-start;
	align-items: center;
}
[data-node-id][custom-blockinfo=error]::before{
	margin-right:10px;

}
[data-node-id][custom-blockinfo=error] [contenteditable]{
	border-left:2px solid #e6af99AA;
	padding-left:10px;
}
/*Block_Info*/
[data-node-id][custom-blockinfo=info]{
	flex-direction:row;
	display: flex;
	justify-content:flex-start;
	align-items: center;
}
[data-node-id][custom-blockinfo=info]::before{
	margin-right:10px;

}
[data-node-id][custom-blockinfo=info] [contenteditable]{
	border-left:2px solid #e6af99AA;
	padding-left:10px;
}
/*Block_Success*/
[data-node-id][custom-blockinfo=success]{
	flex-direction:row;
	display: flex;
	justify-content:flex-start;
	align-items: center;
}
[data-node-id][custom-blockinfo=success]::before{
	margin-right:10px;

}
[data-node-id][custom-blockinfo=success] [contenteditable]{
	border-left:2px solid #e6af99AA;
	padding-left:10px;
}
